A solenoid is made of 100.0 turns of wire, wrapped around a hollow cylinder of radius...

A solenoid is made of 100.0 turns of wire, wrapped around a hollow cylinder of radius 5.000 cm and length 6.000 cm. What is the self-inductance of the solenoid?

___H

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A solenoid is made of 100.0 turns of wire, wrapped around a hollow cylinder of radius...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A long copper wire is wound around a hollow cardboard cylinder to create a solenoid of...

    A long copper wire is wound around a hollow cardboard cylinder to create a solenoid of length 25.8 cm. When 4 A of current flows through the coil, a magnetic field of magnitude 2.25 mT is detected at the center of solenoid. Use this information to determine the number of turns (or loops) of the solenoid. Number of Turus: Enter an integer or decimal number more..

  • 010 (part 1 of 2) 10.0 points A solenoid has 132 turns of wire uniformly wrapped...

    010 (part 1 of 2) 10.0 points A solenoid has 132 turns of wire uniformly wrapped around an air-filled core, which has a diameter of 5 mm and a length of 5.4 cm. The permeability of free space is 1.25664 x 10-6 N/A2. Calculate the self-inductance of the solenoid. Answer in units of H. 011 (part 2 of 2) 10.0 points The core is replaced with a soft iron rod that has the same dimensions, but a magnetic per- meability...

  • A 5.06 10-5 H solenoid is constructed by wrapping 70 turns of wire around a cylinder...

    A 5.06 10-5 H solenoid is constructed by wrapping 70 turns of wire around a cylinder with a cross-sectional area of 8.10 10-4 m2 When the solenoid is shortened by squeezing the turns closer together, the inductance increases to 8.22 10-5 H. Determine the change in the length of the solenoid.

  • A 0.670 m long solenoid is formed by wrapping 480 turns of wire around a hollow...

    A 0.670 m long solenoid is formed by wrapping 480 turns of wire around a hollow cylinder with a radius of 0.200 m. At the instant when the magnetic field in the interior is 0.480 T, calculate the energy stored in the field. * Posted on here already and 5.1 kJ is wrong..

  • A coil of 35 turns is wrapped around a long solenoid of cross-sectional area 5.5 ?...

    A coil of 35 turns is wrapped around a long solenoid of cross-sectional area 5.5 ? 10?3 m2. The solenoid is 0.60 m long and has 600 turns. What is the mutual inductance of this system (in H)? The outer coil is replaced by a coil of 35 turns whose radius is three times that of the solenoid. What is the mutual inductance of this configuration (in H)?

  • A coll of 55 turns is wrapped around a long solenoid of cross-sectional area 5.5 x...

    A coll of 55 turns is wrapped around a long solenoid of cross-sectional area 5.5 x 10"m". The solenoid is 0.40 m long and has 350 turns. (a) What is the mutual inductance of this system (In H)? (b) The outer coll is replaced by a coil of 55 turns whose radius is three times that of the solenoid. What is the mutual inductance of this configuration (in H)?

  • The following solenoid has 200 turns and a length of 15 cm and a radius of...

    The following solenoid has 200 turns and a length of 15 cm and a radius of 2 cm. The current which is going in the direction shown and it VARIES from -2.0 Amperes to 2.0 Amperes in 0.4 seconds. S N What is the self-inductance of the solenoid? What is the induced EMF in the solenoid? • How many turns does a solenoid with length 30 cm needs to have with the same radius to have the same INDUCTANCE as...

  • The following solenoid has 200 turns and a length of 15 cm and a radius of...

    The following solenoid has 200 turns and a length of 15 cm and a radius of 2 cm. The current which is going in the direction shown and it VARIES from -2.0 Amperes to 2.0 Amperes in 0.4 seconds. (12 points) S N • What is the self - inductance of the solenoid? • What is the induced EMF in the solenoid? • How many turns does a solenoid with length 30 cm needs to have with the same radius...

  • A 62.5 m length of insulated copper wire is wound to form a solenoid of radius...

    A 62.5 m length of insulated copper wire is wound to form a solenoid of radius 2.3 cm. The copper wire has a radius of 0.51mm. (Assume the resistivity of copper is  ρ = 1.7 ✕ 10−8 Ω · m.) (a) What is the resistance of the wire?   Ω (b) Treating each turn of the solenoid as a circle, how many turns can be made with the wire?   turns (c) How long is the resulting solenoid?    m (d) What is...

  • An Inductor is made from 20 turns of wire (of negligible resistance), wrapped into a cylinder...

    An Inductor is made from 20 turns of wire (of negligible resistance), wrapped into a cylinder of diameter 25 mm and length 68 mm, around a material of relative permeability 500. 5 more identical Inductors are then constructed, and all 6 of them are connected together in parallel. This network of Inductors is then connected to a 9.0 V cell, of internal resistance 2.0 Ω. Find the magnitude of the initial rate of change of the current flowing through the...
