A weather vane initially at rest has a moment of inertia of 0.113 kg · m2...

A weather vane initially at rest has a moment of inertia of 0.113 kg · m2 about its axis of rotation. A 46.0 g piece of clay is thrown at the vane and sticks to it at a point 14.5 cm from the axis. The initial velocity of the clay is 11.5 m/s, directed perpendicular to the vane. Find the angular velocity of the weather vane just after it is struck.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
