A 2 coulomb positively charged particle starts at rest at the left plate of a pair...
A 2 coulomb positively charged particle starts at rest at the left plate of a pair of parallel plates as shown. If the potential difference between the 2 plates is 4 voles, and the mass of the particle is 1 kg, the speed of the particle when it reaches the second plate is?
A. 16 m/s
B. 2 m/s
C. 1 m/s
D. 4 m/s
E. 263/5 m/hr
Homework Answers
Add Answer to:
A 2 coulomb positively charged particle starts at rest at the
left plate of a pair...
