Light of wavelength 610 nm falls on a slit that is 3.50×10−3 mm wide. How far...

Question

Question

Light of wavelength 610 nm falls on a slit that is 3.50×10⁻³ mm wide.

How far the first bright diffraction fringe is from the strong central maximum if the screen is 10.0 m away.

Express your answer to three significant figures and include the appropriate units.

science physics

Answer 1

Answer #1
