A cube of mass m is initially at rest at the peak of an inclined plane,...
A cube of mass m is initially at rest at the peak of an inclined plane, which has a height of 6.2 m and has an angle of θ = 16° with respect to the horizontal. After it has been released, it is found to be moving at v = 0.35 m/s a distance d after the end of the inclined plane as shown. The coefficient of kinetic friction between the cube and the plane is μp = 0.1, and the coefficient of friction on the horizontal surface is μr = 0.2.
50% Part (a) What is the speed of the cube, in meters per second, just after it leaves the inclined plane?
50% Part (b) Find the distance, d, in meters.
Homework Answers
Add Answer to:
A cube of mass m is initially at rest at the peak of an inclined
plane,...
A block of mass m is initially at rest at the top of an inclined plane,...
A block of mass m is initially at rest at the top of an inclined plane, which has a height of 6.2 m and makes an angle of θ = 22° with respect to the horizontal. After being released, it is observed to be traveling at v = 0.65 m/s a distance d after the end of the inclined plane as shown. The coefficient of kinetic friction between the block and the plane is μp = 0.1, and the coefficient...
A brick of mass m is initially at rest at the highest point of an inclined plane, which has a height of 5.1 m and makes an angle of θ = 17° with respect to the horizontal.
Problem 2: A brick of mass m is initially at rest at the highest point of an inclined plane, which has a height of 5.1 m and makes an angle of θ = 17° with respect to the horizontal. After being released, you perceive it to be traveling at v = 0.45 m/s a distance d after the end of the inclined plane as shown. The coefficient of kinetic friction between the brick and the plane is μp =0.1, and...
There is a cube of mass m with a v_0 of 0 at the highest point...
There is a cube of mass m with a v_0 of 0 at the highest point of a plane is inclined. This inclined plane has an angle of θ = 24° with respect to the horizontal and a height of 4.7 m. Once it is released, it is moving with a v=0.55 m/s at a distance d after the end of the inclined plane. The kinetic friction coefficient between the block and plane is μp = 0.1. The coefficient of...
A block of mass m is initially at rest at the top of an inclined plane, which has a height of 5.6 m and makes an angle of θ = 21° with respect to the horizontal
A block of mass m is initially at rest at the top of an inclined plane, which has a height of 5.6 m and makes an angle of θ = 21° with respect to the horizontal. After being released, it is observed to be traveling at v = 0.55 m/s a distance d after the end of the inclined plane as shown. The coefficient of kinetic friction between the block and the plane is μp = 0.1, and the coefficient...
A 10 kg block is placed on an inclined plane that is at an angle of...
A 10 kg block is placed on an inclined plane that is at an angle of 30 degrees with respect to the horizontal. THe coefficient of kinetic friction between the block and the plane is .1. The block is released from rest at 5m above a spring that is also lying on the plane. The spring has a constant of 50 N/m. What is the max compression of the spring?
an 8kb block starts from rest from the top of a plane, inclined at 40 degrees...
an 8kb block starts from rest from the top of a plane, inclined at 40 degrees with respect to the horizontal, and slides down at a constant acceleration. if the coefficient of kinetic friction between the block and the plane is 0.35, determine how far the block will travel in 3 seconds.
(0%) Problem 12: Ablock of mass m 2.1 kg is on an inclined plane with a...
(0%) Problem 12: Ablock of mass m 2.1 kg is on an inclined plane with a coefficient of friction u 0.36, at an initial height h = 0.44 m above the ground. The plane is inclined at an angle 0 51°. The block is then compressed against a spring a distance Ax 0.17m from its equilibrium point (the spring has a spring constant of ky =27 N/m) and released. At the bottom of the inclined plane is a horizontal plane...
A block of mass m is placed in a smooth-bored spring gun at the bottom of an inclined plane
A block of mass m is placed in a smooth-bored spring gun at the bottom of an inclined plane, such that it compresses the spring by an amount xc, as shown in the figure below. The spring has a spring constant k. The incline makes an angle θ with the horizontal and the coefficient of friction between the block and the inclined plane is μ. The block is released, exits the muzzle of the gun, and slides up the incline...
A block of mass m = 3.5 kg is on an inclined plane with a coefficient...
A block of mass m = 3.5 kg is
on an inclined plane with a coefficient of friction
μ1 = 0.31, at an
initial height h = 0.53 m above
the ground. The plane is inclined at an angle θ =
54°. The block is then compressed against
a spring a distance Δx = 0.11 m
from its equilibrium point (the spring has a spring constant of
k1 = 39 N/m) and
released. At the bottom of the inclined plane...
The fiqure below shows a solid cube with a mass m on an inclined plane, at...
The fiqure below shows a solid cube with a mass m on an inclined plane, at angle e above horizontal. R The cube is attached at one end to a spring with spring constant k at one end and a lightweight string at the other. The string is in turn wound around a reel with a radius R and moment of inertia I. The axle of the reel and the incline both have negligible friction The reel is turned counterclockwise...
(0%) Problem 12: Ablock of mass m 2.1 kg is on an inclined plane with a coefficient of friction u 0.36, at an initial height h = 0.44 m above the ground. The plane is inclined at an angle 0 51°. The block is then compressed against a spring a distance Ax 0.17m from its equilibrium point (the spring has a spring constant of ky =27 N/m) and released. At the bottom of the inclined plane is a horizontal plane...
A block of mass m = 3.5 kg is
on an inclined plane with a coefficient of friction
μ1 = 0.31, at an
initial height h = 0.53 m above
the ground. The plane is inclined at an angle θ =
54°. The block is then compressed against
a spring a distance Δx = 0.11 m
from its equilibrium point (the spring has a spring constant of
k1 = 39 N/m) and
released. At the bottom of the inclined plane...
The fiqure below shows a solid cube with a mass m on an inclined plane, at angle e above horizontal. R The cube is attached at one end to a spring with spring constant k at one end and a lightweight string at the other. The string is in turn wound around a reel with a radius R and moment of inertia I. The axle of the reel and the incline both have negligible friction The reel is turned counterclockwise...
