1) A semicircle of radius R0 [m] on the xy plane with its center at the...
1) A semicircle of radius R0 [m] on the xy plane with its center
at the origin has a charge
total Q [C] evenly distributed. Find the electrical potential over
at a point at 2R0 [m]
on the z axis.
2)A rod of length L [m] has a total load Q [C] distributed with
a density of
constant load Using the definition of electric field between point
charges find the field
electric at a point on the shaft of the rod at a distance L [m]
from one of its ends.
