Question

Create a system to simulate vehicles at an intersection. Assume that there is one lane going in each of four directions, with stoplights facing each direction. Vary the arrival average of vehicles in each direction and the frequency of the light changes to view the “behavior” of the intersection.

PLEASE PROVIDE A JAVA CODE....

THANKS

Answer 1

Code:

EmptyCollectionException.java:

public class EmptyCollectionException extends RuntimeException

{

public EmptyCollectionException(String collection)

{

super("The " + collection + " is empty.");

}

}

LinkedQueue.java:

public class LinkedQueue<T> implements QueueADT<T>
{
private int cnt;
private vecLinearNode<T> front, rear;
public LinkedQueue()
{
cnt = 0;
front = rear = null;
}

public void vecenqueue(T element)
{
vecLinearNode<T> unit = new vecLinearNode<T>(element);
if (vecisEmpty())
front = unit;
else
rear.vecsetNext(unit);
rear = unit;
cnt++;
}

public T vecdequeue() throws EmptyCollectionException
{
if (vecisEmpty())
throw new EmptyCollectionException("queue");
T res = front.vecgetElement();
front = front.vecgetNext();
cnt--;
if (vecisEmpty())
rear = null;
return res;
}

public T vecfirst() throws EmptyCollectionException
{
if(!vecisEmpty())
return(front.vecgetElement());
else
throw new EmptyCollectionException("Nothing to peek");
}

public boolean vecisEmpty()
{
return(cnt == 0);
}

public int size()
{
return(cnt);
}

public String vectoString()
{
String qStr = "";
try
{
vecLinearNode<T> ele = front;
T elem2 = ele.vecgetElement();
for(int i = cnt; i > 0; i--)
{
qStr += (elem2);

if(i > 1)
{
qStr += "\n";
ele = ele.vecgetNext();
elem2 = ele.vecgetElement();
}
}
}

catch(NullPointerException e)
{
System.err.println("The tail is empty");
}
return qStr;
}
}
QueueADT.java:

public interface QueueADT<T>
{
public void vecenqueue(T element);
public T vecdequeue();
public T vecfirst();
public boolean vecisEmpty();
public String vectoString();
}
vecDriver.java:

public class vecDriver
{
public static void main (String[] args)
{
vecSimulator vecsimulator = new vecSimulator();
vecsimulator.vecSimulate();
}
}
vecLinearNode.java:

public class vecLinearNode<T>
{
private vecLinearNode<T> next;
private T element;
public vecLinearNode()
{
next = null;
element = null;
}

public vecLinearNode(T elem)
{
next = null;
element = elem;
}

public vecLinearNode<T> vecgetNext()
{
return next;
}

public void vecsetNext(vecLinearNode<T> node)
{
next = node;
}

public T vecgetElement()
{
return element;
}

public void vecsetElement(T elem)
{
element = elem;
}
}
vecSimulator.java:

import java.lang.Math;

import java.io.*;

import java.util.*;

import java.net.*;

import java.io.*;

public class vecSimulator

{

private LinkedQueue<vecVehicle> EL = new LinkedQueue<vecVehicle>();

private LinkedQueue<vecVehicle> ER = new LinkedQueue<vecVehicle>();

private LinkedQueue<vecVehicle> WL = new LinkedQueue<vecVehicle>();

private LinkedQueue<vecVehicle> WR = new LinkedQueue<vecVehicle>();

private LinkedQueue<vecVehicle> NL = new LinkedQueue<vecVehicle>();

private LinkedQueue<vecVehicle> NR = new LinkedQueue<vecVehicle>();



private LinkedQueue<vecVehicle> SCL = new LinkedQueue<vecVehicle>();



private LinkedQueue<vecVehicle> SCR = new LinkedQueue<vecVehicle>();

int t = 0;

int i = 0;

int v_num = 1;

FileWriter fw;

BufferedWriter bw;

PrintWriter pw;

// invoke the Constructor

public vecSimulator() {}

// write the result to file by calling other methods

public void vecSimulate()

{

try

{

fw = new FileWriter("output.txt");

bw = new BufferedWriter(fw);

pw = new PrintWriter(bw);

pw.print("+++++++++++++++++++++++++++++++++++++++++++++++ \n");

pw.print(" | | \n");

pw.print(" | AUTOMATIC TRAFFIC SIMULATION | \n");

pw.print(" | | \n");

pw.print("+++++++++++++++++++++++++++++++++++++++++++++++ \n");

pw.print("\n");

vecpopulate((int)(Math.random() * (13 - 7) + 7));

while(!vecqueuesEmpty())

{

pw.print("\n\n |||-------------------------------||| \n");

pw.print(" ||| TRAFFIC ALTERED ||| \n");

pw.print(" ||| N/S-bound is active |||\n");



pw.print(" |||-------------------------------||| \n");

vecmoveNorthSouth();

vecpopulate((int)(Math.random() * (16 - 8) + 8));

pw.println();

pw.print("\n\n |||-------------------------------||| \n");

pw.print(" ||| TRAFFIC ALTERED ||| \n");

pw.print(" ||| E/W-bound is active |||\n");



pw.print(" |||-------------------------------||| \n");

vecmoveEastWest();

vecpopulate((int)(Math.random() * (16 - 3) + 3));

pw.println();

}

pw.close();

}

catch(IOException e)

{

System.err.println("Error printing to file");

}

}

// intersection is populated here

private void vecpopulate(int randomNum)

{

int count = 0;

while (count < randomNum && v_num <=120)

{

vecVehicle car = new vecVehicle(v_num, t, t);

count++;

v_num++;

if (car.vecgetStreet() == vecVehicle.vecStreet.Main && car.vecgetDirection() == vecVehicle.vecDirection.E && car.vecgetLane() == vecVehicle.vecLane.Left)

EL.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Main && car.vecgetDirection() == vecVehicle.vecDirection.E && car.vecgetLane() == vecVehicle.vecLane.Right)

ER.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Main && car.vecgetDirection() == vecVehicle.vecDirection.W && car.vecgetLane() == vecVehicle.vecLane.Left)

WL.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Main && car.vecgetDirection() == vecVehicle.vecDirection.W && car.vecgetLane() == vecVehicle.vecLane.Right)

WR.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Church && car.vecgetDirection() == vecVehicle.vecDirection.N && car.vecgetLane() == vecVehicle.vecLane.Left)

NL.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Church && car.vecgetDirection() == vecVehicle.vecDirection.N && car.vecgetLane() == vecVehicle.vecLane.Right)

NR.vecenqueue(car);

else if (car.vecgetStreet() == vecVehicle.vecStreet.Church && car.vecgetDirection() == vecVehicle.vecDirection.S && car.vecgetLane() == vecVehicle.vecLane.Left)

SCL.vecenqueue(car);

else

SCR.vecenqueue(car);

}

}

// vehicle movement is tracked here

private void vecmoveNorthSouth()

{

int i = 0;

while (i < 2)

{

t+=3;

try

{

if (!NL.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = NL.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);



}

}

catch(EmptyCollectionException e) {}

try

{

if (!NR.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = NR.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

try

{

if (!SCL.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = SCL.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

try

{

if (!SCR.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = SCR.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

i++;

}

}

// east to west movement

private void vecmoveEastWest()

{

int i = 0;

while (i < 3)

{

t+=3;

try

{

if (!EL.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = EL.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

try

{

if (!ER.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = ER.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

try

{

if (!WL.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = WL.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

try

{

if (!WR.vecisEmpty())

{

vecVehicle car = new vecVehicle(0,0,0);

car = WR.vecdequeue();

car.vecsetDepartureTime(t);

pw.print(" ");

pw.println(car);

}

}

catch(EmptyCollectionException e) {}

i++;

}

}

// clears the queue

private boolean vecqueuesEmpty()

{

boolean empty;



empty = EL.vecisEmpty();

if(empty)

empty = ER.vecisEmpty();

if(empty)

empty = WL.vecisEmpty();

if(empty)

empty = WR.vecisEmpty();

if(empty)

empty = NL.vecisEmpty();

if(empty)

empty = NR.vecisEmpty();

if(empty)

empty = SCL.vecisEmpty();

if(empty)

empty = SCR.vecisEmpty();

return empty;

}

}

vecVehicle.java:

public class vecVehicle
{
public enum vecDirection{N, E, S, W};
public enum vecStreet{Main, Church};
public enum vecLane{Left, Right};
private int vehicleNumber;
private int arrivalTime;
private int departureTime;
private vecStreet street;
private vecDirection direction;
private vecLane lane;
private String bound;
private String continuation;

// call the Constructor
public vecVehicle (int vehicleNum, int aTime, int dTime)
{
vehicleNumber = vehicleNum;
arrivalTime = aTime;
departureTime = dTime;
direction = vecrandomDirection();
street = vecrandomStreet();
lane = vecrandomLane();
}

// randomly assign the direction
public vecDirection vecrandomDirection()
{
int dirIndicator = (int)(Math.random() * (4 - 0) + 0);
if(dirIndicator == 1)
direction = vecDirection.N;
else if(dirIndicator == 2)
direction = vecDirection.E;
else if(dirIndicator == 3)
direction = vecDirection.S;
else
direction = vecDirection.W;
return direction;
}

// determine the street randomly
public vecStreet vecrandomStreet()
{
if(direction == vecDirection.N || direction == vecDirection.S)
{
street = vecStreet.Church;
}
else
street = vecStreet.Main;
return street;
}

// assign vehicles randomly in lanes
public vecLane vecrandomLane()
{
int laneIndicator = (int)(Math.random() * (2 - 0) + 0);
if (laneIndicator ==1)
lane =vecLane.Left;
else
lane = vecLane.Right;
return lane;
}

// to get the direction
public vecDirection vecgetDirection()
{
return direction;
}

// view the street of a vehicle.
public vecStreet vecgetStreet()
{
return street;
}

// view from which lane the vehicle came.
public vecLane vecgetLane()
{
return lane;
}

// set the departure of vehicles in lanes.
public void vecsetDepartureTime(int time)
{
departureTime = time;
}

// get vehicle number.
public int vecgetVehicleNumber()
{
return vehicleNumber;
}

// associate the direction
public String vecgetBound()
{
if (direction == vecDirection.S)
return "southbound";
else if (direction == vecDirection.N)
return "northbound";
else if (direction == vecDirection.W)
return "westbound";
else
return"eastbound";
}

// defines the continuation
private String vecgetContinuation()
{
if (lane == vecLane.Left)
return "continued straight";
else if (lane ==vecLane.Right && direction == vecDirection.S)
return "turned right and headed westbound";
else if (lane ==vecLane.Right && direction == vecDirection.N)
return "turned right and headed eastbound";

else if (lane ==vecLane.Right && direction == vecDirection.W)

return "turned right and headed northbound";
else

return "turned right and headed southbound";

}

// determine the time as required format
public String vectoString()
{
String waittime = String.format("%02d",(departureTime - arrivalTime));

return "[Time " + String.format("%02d", departureTime) + "] Vehicle #" + vehicleNumber + " (" + vecgetBound() + ") " + vecgetContinuation() + ". Total wait time " + waittime + " seconds.";
}
}
