Three forces in the x-y plane act on a 3.40 kg mass: 13.10 N directed at...
Three forces in the x-y plane act on a 3.40 kg mass: 13.10 N directed at 51o, 7.00 N directed at 109o, and 6.80 N directed at 240o. All angles are measured from the positive x-axis, with positive angles in the Counter-Clockwise direction.
a) Calculate the magnitude of the acceleration.
b) Calculate the direction of the resultant force using the same sign convention as above (in degrees).
Homework Answers
Add Answer to:
Three forces in the x-y plane act on a 3.40 kg mass: 13.10 N
directed at...
Three forces in the x-y plane act on a 3.70 kg mass: 16.70 N directed at...
Three forces in the x-y plane act on a 3.70 kg mass: 16.70 N directed at 50o, 11.20 N directed at 168o, and 4.40 N directed at 233o. All angles are measured from the positive x-axis, with positive angles in the Counter-Clockwise direction. Calculate the magnitude of the acceleration. Calculate the direction of the resultant force using the same sign convention as above (in degrees).
Two horizontal forces act on a 55 kg object. One force has magnitude 65N directed 59...
Two horizontal forces act on a 55 kg object. One force has magnitude 65N directed 59 degrees clockwise from the positive x axis, and the other has a magnitude 35 N at 32 degrees clockwise from the positive y axis. What is the magnitude of this object's acceleration?
Two forces, F⃗1 and F⃗2, act at a point, as shown in the picture.
Two forces, F⃗1 and F⃗2, act at a point, as shown in the
picture. (Figure 1) F⃗1 has a magnitude of 8.80 N and is directed
at an angle of α = 62.0 ∘ above the negative x axis in the second
quadrant. F⃗2 has a magnitude of 7.00 N and is directed at an
angle of β = 52.3 ∘ below the negative x axis in the third
quadrant. Part A What is the x component Fx of the resultant force? Part...
Forces of 70 N at 50 degrees, and 20 N at an angle of 220 degrees,...
Forces of 70 N at 50 degrees, and 20 N at an angle of 220 degrees, measured counter-clockwise from the positive x-axis, act on an object. What is the magnitude of the resultant force (in Newtons)? What is the angle of the resultant force with respect to x-axis? (positive values only)
Forces of 70 N at 60 degrees, and 20 N at an angle of 220 degrees,...
Forces of 70 N at 60 degrees, and 20 N at an angle of 220 degrees, measured counter-clockwise from the positive x-axis, act on an object. What is the magnitude of the resultant force (in Newtons)? What is the angle of the resultant force with respect to x-axis? (positive values only)
Forces of 70 N at 40 degrees, and 10 N at an angle of 230 degrees,...
Forces of 70 N at 40 degrees, and 10 N at an angle of 230 degrees, measured counter-clockwise from the positive x-axis, act on an object. What is the magnitude of the resultant force (in Newtons)? What is the angle of the resultant force with respect to x-axis? (positive values only)
Two forces, F⃗ 1 and F⃗ 2, act at a point, as shown in the picture....
Two forces, F⃗ 1 and F⃗ 2, act at a point, as shown in the picture. (Figure 1) F⃗ 1 has a magnitude of 9.00 N and is directed at an angle of α = 58.0 ∘ above the negative x axis in the second quadrant. F⃗ 2 has a magnitude of 7.00 N and is directed at an angle of β = 52.9 ∘ below the negative x axis in the third quadrant. PART A: What is the x...
Forces of 80 N at 70 degrees, and 40 N at an angle of 220 degrees,...
Forces of 80 N at 70 degrees, and 40 N at an angle of 220 degrees, measured counter-clockwise from the positive x-axis, act on an object What is the magnitude of the resultant force (in Newtons) Submit Answer Tries 0/2 What is the angle of the resultant force with respect to x-axis? (positive values only) Submit Answer Tries 0/2
Two forces, F1 and F2, act at a point, as shown in the picture. (Figure 1)...
Two forces, F1 and F2, act at a point, as
shown in the picture. (Figure 1) F1 has a magnitude of
8.40 N and is directed at an angle of a = 59.0 ? above the
negative xaxis in the second quadrant. F2 has a
magnitude of 6.40 N and is directed at an angle of b =
54.1 ? below the negative x axis in the third
quadrant.
a) What is the x component Fx of the resultant
force? Express...
Two forces, F1 and F2, act at a point, as shown in the picture
Two forces, F1 and F2, act at a point, as shown in the picture. F1 has a magnitude of 9.60 N and is directed at an angle of α = 58.0° above the negative x axis in the second quadrant. F2 has a magnitude of 5.80 N and is directed at an angle of β = 52.5° below the negative x axis in the third quadrant.Part A What is the x component Fx of the resultant force? Part B What is...
Forces of 70 N at 50 degrees, and 20 N at an angle of 220 degrees, measured counter-clockwise from the positive x-axis, act on an object. What is the magnitude of the resultant force (in Newtons)? What is the angle of the resultant force with respect to x-axis? (positive values only)
Forces of 80 N at 70 degrees, and 40 N at an angle of 220 degrees, measured counter-clockwise from the positive x-axis, act on an object What is the magnitude of the resultant force (in Newtons) Submit Answer Tries 0/2 What is the angle of the resultant force with respect to x-axis? (positive values only) Submit Answer Tries 0/2
Two forces, F1 and F2, act at a point, as
shown in the picture. (Figure 1) F1 has a magnitude of
8.40 N and is directed at an angle of a = 59.0 ? above the
negative xaxis in the second quadrant. F2 has a
magnitude of 6.40 N and is directed at an angle of b =
54.1 ? below the negative x axis in the third
quadrant.
a) What is the x component Fx of the resultant
force? Express...
