An 80 kg man stands in a very strong wind moving at 17 m/s at torso...
An 80 kg man stands in a very strong wind moving at 17 m/s at torso height. As you know, he will need to lean in to the wind, and we can model the situation to see why. Assume that the man has a mass of 80 kg, with a center of gravity 1.0 m above the ground. The action of the wind on his torso, which we approximate as a cylinder 50 cm wide and 90 cm long centered 1.2 m above the ground, produces a force that tries to tip him over backward. To keep from falling over, he must lean forward. What is the magnitude of the torque provided by the wind force? Take the pivot point at his feet. Assume that he is standing vertically. Assume that the air is at standard temperature and pressure.
Homework Answers
Add Answer to:
An 80 kg man stands in a very strong wind moving at 17 m/s at
torso...
A 90 kg man stands in a very strong wind moving at 12 m/s at torso...
A 90 kg man stands in a very strong wind moving at 12 m/s at torso height. As you know, he will need to lean in to the wind, and we can model the situation to see why. Assume that the man has a mass of 90 kg, with a center of gravity 1.0 m above the ground. The action of the wind on his torso, which we approximate as a cylinder 50 cm wide and 90 cm long centered...
When a man stands near the edge of an empty drainage ditch of depth 2.80 m,...
When a man stands near the edge of an empty drainage ditch of depth 2.80 m, he can barely see the boundary between the opposite wall and bottom of the ditch as in Figure (a) shown below. The distance from his eyes to the ground is h-1.99 m. (Assume θ-29.70.) トd 2.80 m (a) What is the horizontal distance d from the man to the edge of the drainage ditch? d= (b) After the drainage ditch is filled with water...
A 60 kg stunt man is falling at 15 m/s when he comes into contact with...
A 60 kg stunt man is falling at 15 m/s when he comes into contact with a large safety air bag. In coming to a stop, the air bag exerts a force of -1200 N on the man. How long was the air mattress being used to slow his fall? (please provide me with the equation to solve and the steps to get to the answer)
3. 1072 4 m/s 26 A 80 kg Prof. Sukanek wearing ice skates stands motionless on...
3. 1072 4 m/s 26 A 80 kg Prof. Sukanek wearing ice skates stands motionless on the ice when he throws a 8 kg block with a velocity as shown in the figure. Assume he keeps his legs rigid during the throw and neglect friction and the motion of his arms. Use right and up as the positive directions. NOTES IMAGES DISCUSS UNITS STATS HELP PREFERENCES Part Description Answer Chk History A. 6.82 pts. 75% Assume he completes the throw...
A 76 kg man drops to a concrete patio from a window only 0.55 m above...
A 76 kg man drops to a concrete patio from a window only 0.55 m above the patio. He neglects to bend his knees on landing, taking 2.0 cm to stop. (a) What is his average acceleration from when his feet first touch the patio to when he stops? m/s2 (b) What is the magnitude of the average stopping force? kN
A man of mass 86 kg drops to a concrete patio from a window 0.43 m...
A man of mass 86 kg drops to a concrete patio from a window 0.43 m above the patio. He neglects to bend his knees on landing, taking 2.5 cm to stop. (a) What is his average acceleration from when his feet first touch the patio to when he stops? (b) What is the magnitude of the average stopping force exerted on him by the patio?
A 68 kg bungee jumper is standing on a platform 46 m above the ground. The...
A 68 kg bungee jumper is standing on a platform 46 m above the ground. The jumper falls from rest and it is assumed that the bungee cord, which is attached to the bungee jumper at one end and the platform at the other, has no effect for the first 9 m of the fall, i.e. the natural length of the cord is 9 m. When the bungee jumper is more than 9 m away from the platform the cord...
2 out of 3 attempts A man is trying to lift 67.2 kg off the floor...
2 out of 3 attempts A man is trying to lift 67.2 kg off the floor by bending at the waist. Assume that the man's Assist upper body weighs 495 N and the upper body's center of gravity is 38.0 cm from the sacrum (tailbone) Checi Try An View H View Q Show M Guided Practice Force due to back muscles Force due to sacrum (Fs) Spine Axis (sacrum) Weight of upper body (mg Print 38.0 cm 73.3 cm A...
A flamingo is able to stand on one leg without using any muscles. It can do...
A flamingo is able to stand on one leg without using any muscles. It can do this by locking its leg joints so that it acts as a rigid body. (a) If the height of the centre of mass is 110 cm above the ground, and the width of the flamingo's foot is 10 cm. What angle would the Flamingo be able to tilt without falling over? We can use a mass of 3.5 kg for the bird 110cm 10cm...
Problem 1: A car of mass 1000 kg moves at a constant speed of 20 m/s...
Problem 1: A car of mass 1000 kg moves at a constant speed of 20 m/s along a horizontal road where a frictional force is 200N. Calculate the power developed by the engine. If the car now moves up an incline at the same constant speed, calculate the new power developed by the engine. Assume that the frictional force is still 200 N and that sin(theta)=1/20 where theta is the angle of the incline to the horizontal. Problem 2: An...
When a man stands near the edge of an empty drainage ditch of depth 2.80 m, he can barely see the boundary between the opposite wall and bottom of the ditch as in Figure (a) shown below. The distance from his eyes to the ground is h-1.99 m. (Assume θ-29.70.) トd 2.80 m (a) What is the horizontal distance d from the man to the edge of the drainage ditch? d= (b) After the drainage ditch is filled with water...
3. 1072 4 m/s 26 A 80 kg Prof. Sukanek wearing ice skates stands motionless on the ice when he throws a 8 kg block with a velocity as shown in the figure. Assume he keeps his legs rigid during the throw and neglect friction and the motion of his arms. Use right and up as the positive directions. NOTES IMAGES DISCUSS UNITS STATS HELP PREFERENCES Part Description Answer Chk History A. 6.82 pts. 75% Assume he completes the throw...
A 68 kg bungee jumper is standing on a platform 46 m above the ground. The jumper falls from rest and it is assumed that the bungee cord, which is attached to the bungee jumper at one end and the platform at the other, has no effect for the first 9 m of the fall, i.e. the natural length of the cord is 9 m. When the bungee jumper is more than 9 m away from the platform the cord...
2 out of 3 attempts A man is trying to lift 67.2 kg off the floor by bending at the waist. Assume that the man's Assist upper body weighs 495 N and the upper body's center of gravity is 38.0 cm from the sacrum (tailbone) Checi Try An View H View Q Show M Guided Practice Force due to back muscles Force due to sacrum (Fs) Spine Axis (sacrum) Weight of upper body (mg Print 38.0 cm 73.3 cm A...
A flamingo is able to stand on one leg without using any muscles. It can do this by locking its leg joints so that it acts as a rigid body. (a) If the height of the centre of mass is 110 cm above the ground, and the width of the flamingo's foot is 10 cm. What angle would the Flamingo be able to tilt without falling over? We can use a mass of 3.5 kg for the bird 110cm 10cm...
Problem 1: A car of mass 1000 kg moves at a constant speed of 20 m/s along a horizontal road where a frictional force is 200N. Calculate the power developed by the engine. If the car now moves up an incline at the same constant speed, calculate the new power developed by the engine. Assume that the frictional force is still 200 N and that sin(theta)=1/20 where theta is the angle of the incline to the horizontal. Problem 2: An...
