can please somebody answer me this questions with solution.
1) Find the 12-bit product of 101011 x 100111 assuming that the binary numbers are signed integers in two's complement form.
2) Find the quotient and the remainder of 11010111 ÷ 1010, assuming that the binary numbers are signed integers in two's complement form.
-
Let 4284000016 and 3c82000016 represent two floating point numbers in IEEE single-precision FP format.
-
Determine the decimal values of the two numbers.
-
Add the two numbers and show the result both in IEEE single-precision FP format and in decimal.
-
Multiply the two numbers and show the result both in IEEE single-precision FP format and in decimal.
-
