Question

Lab 2: Design Lab

Purpose:

Create a sample ER diagram for database design.

Deliverables:

A Microsoft Visioor Word drawing of the design: draw tables with table title, primary key(s), foreign key(s) and relationships (using connections) specified properly; you are also supposed to bold or indicate the required columns/fields for each table. If you need to, a brief explanation of your design.[1]

Steps:

1. Follow the steps described in class. Create a DB design for the business problem described below[2]. Explain your design choices. 1

Create a sample DB design for a small bakery. The bakery is interested in keeping track of its customers, suppliers, products, ingredients and sales. Bakery sells their products to the customers. Bakery uses the ingredients to create their products. Suppliers provide the ingredients to the bakery.

[1] This is optional - at most, a paragraph or two - very short, only listing the NON-obvious choices.

[2] Think about what data makes sense for the business problem and select the fields that make the most sense. Expected design scope is somewhere around 7-10 tables, 2-6 or so fields/table on average – your design does not need 100 of fields, but it does need to be able to function on its own.

Answer 1

ER Diayram fry Small Bakery As per the Iinfrsmakion fm alven tion dia.ks ainuhi' tr Bake엉 makittu products using ire -dale Sapplier ingpedients Customers

ingedien-G-I'd (pk), inarue , sid (F. k), am , s-dak produch (is Cx, pmame, parca, ia (F) a vtomex (cid (pr) cname, pid (F k), bil) Saluy cid, pid, bill)
