If light is moving from water (n=1.33) to glass (1.5) at an angle of 25 degrees,...

Question

Question

If light is moving from water (n=1.33) to glass (1.5) at an angle of 25 degrees, what is the refracted angle?

Is it possible to have a critical angle? If so what is it? If not explain.

science physics

Answer 1

Answer #1

Soch Shells law n, sino = n2 Simon a water 1.33 Sin280 = 1.5sin Oz nz 023 21.960 Ans For critical angle 022 900 1.33 sin oor

Answer 2
