Light from a He-Ne laser of wavelength 633 nm passes through a circular aperture. It is...
Light from a He-Ne laser of wavelength 633 nm passes through a circular aperture. It is observed on a screen 4.0 m behind the aperture. The width of the central maximum is 1.1 cm. What is the diameter of the hole?
a. 3.2×104 μm
b. 560 μm
c. 4700 μm
d. 9.8 μm
