When blue light of wavelength 470 nm falls on a single slit, the first dark bands...

Question

Question

When blue light of wavelength 470 nm falls on a single slit, the first dark bands on either side of center are separated by 51.0 degrees

Determine the width of the slit.

science physics

Answer 1

Answer #1

Answer 2
