A proton traveling to the right along the x-axis enters a region where there is a...
A proton traveling to the right along the x-axis enters a region where there is a mag- netic field of magnitude 2.5 T directed upward along the y-axis. The charge on a proton is 1.60×10−19. If the proton experiences a force of 3.7 × 10−12 N, find its speed. Answer in units of m/s.
Homework Answers
Add Answer to:
A proton traveling to the right along the x-axis enters a region
where there is a...
Question 20 A charged particle moving to the right along the x-axis enters a region with...
Question 20 A charged particle moving to the right along the x-axis enters a region with a uniform electric field that is directed along the y-axis from the top of the page to the bottom of the page, as shown in the figure below. Which of the following statements is NOT true about the subsequent motion of the charged particle? You may neglect the effects of gravity and air resistance for this question. Select the correct aneu Select the correct...
An electron traveling toward the north with speed 4.0 x 10 m/s enters a region where...
An electron traveling toward the north with speed 4.0 x 10 m/s enters a region where the Earth's magnetic field has the magnitude 5.0 x 10 ST and is directed downward at 45° below horizontal. What is the magnitude of the acceleration of the electron? (e = 1.60 10-19 C, mel = 9.11 10-31 kg) 9.8 m/s2 2.5 1012 m/s2 6.3 X 10-30 m/s2 3.2 x 10-18 m/s2
2) An electron traveling toward the north with speed 6.0 * 105 m's enters a region...
2) An electron traveling toward the north with speed 6.0 * 105 m's enters a region where the Earth's magnetic field has the magnitude 15.0 x 10-5 T and is directed downward at 450 below horizontal. What is the magnitude of the force that the Earth's magnetic field exerts on the electron? (e-1.60 10-19 C) (10 points) ttttt
A proton, initially traveling in the +x-direction with a speed of 5.15×105 m/s , enters a...
A proton, initially traveling in the +x-direction with a speed of 5.15×105 m/s , enters a uniform electric field directed vertically upward. After traveling in this field for 3.96×10−7 s , the proton’s velocity is directed 45 ∘ above the +x-axis. Part A What is the strength of the electric field?
An electron traveling horizontally enters a region where a uniform electric field of 15 N/C is...
An electron traveling horizontally enters a region where a uniform electric field of 15 N/C is directed upward. What is the magnitude and direction of the force exerted on the electron once it has entered the field?
A proton moving to the right at 6.2 × 105 ms-1 enters a region where there...
A proton moving to the right at 6.2 × 105 ms-1 enters a region where there is an electric field of 62 kNC-1 directed to the left. Describe qualitatively the motion of the proton in this filed. What is the time taken by the proton to come back to the point where it entered the field? (Use the standard values of the mass and charge of a proton)
3. An electron traveling horizontally enters a region where a uniform electric field is directed upward....
3. An electron traveling horizontally enters a region where a uniform electric field is directed upward. What is the direction of the force exerted on the electron once it has entered the field? A) to the left D) downward electrou B) to the right E) out of the page, toward the reader C) upward
3. If a proton is moving along the x-axis at 8/10 times the speed of light...
3. If a proton is moving along the x-axis at 8/10 times the speed of light in vacuum, through a region of space where the Electric field is 2i and the Magnetic field 3i+4j, find the magnitude of the force on the proton.
A particle with the same mass and charge as a proton enters a region where the...
A particle with the same mass and charge as a proton enters a region where the magnetic field has a magnitude of 4000 G. The particle moves in a circular path of radius of 20 cm. Determine the speed and period of the particle in the magnetic field.
A proton traveling at v= 4.65 x 10° m/s to the right enters the region between...
A proton traveling at v= 4.65 x 10° m/s to the right enters the region between two parallel charged plates separated by a distance d = 5.09 cm that also contains a uniform magnetic field out of the page of field strength B = 8.47 ut. a What does the potential difference across the plates have to be for the proton to continue traveling at constant velocity? Express your answer using two decimal places. Your answer should be in V.
Question 20 A charged particle moving to the right along the x-axis enters a region with a uniform electric field that is directed along the y-axis from the top of the page to the bottom of the page, as shown in the figure below. Which of the following statements is NOT true about the subsequent motion of the charged particle? You may neglect the effects of gravity and air resistance for this question. Select the correct aneu Select the correct...
An electron traveling toward the north with speed 4.0 x 10 m/s enters a region where the Earth's magnetic field has the magnitude 5.0 x 10 ST and is directed downward at 45° below horizontal. What is the magnitude of the acceleration of the electron? (e = 1.60 10-19 C, mel = 9.11 10-31 kg) 9.8 m/s2 2.5 1012 m/s2 6.3 X 10-30 m/s2 3.2 x 10-18 m/s2
2) An electron traveling toward the north with speed 6.0 * 105 m's enters a region where the Earth's magnetic field has the magnitude 15.0 x 10-5 T and is directed downward at 450 below horizontal. What is the magnitude of the force that the Earth's magnetic field exerts on the electron? (e-1.60 10-19 C) (10 points) ttttt
3. An electron traveling horizontally enters a region where a uniform electric field is directed upward. What is the direction of the force exerted on the electron once it has entered the field? A) to the left D) downward electrou B) to the right E) out of the page, toward the reader C) upward
A proton traveling at v= 4.65 x 10° m/s to the right enters the region between two parallel charged plates separated by a distance d = 5.09 cm that also contains a uniform magnetic field out of the page of field strength B = 8.47 ut. a What does the potential difference across the plates have to be for the proton to continue traveling at constant velocity? Express your answer using two decimal places. Your answer should be in V.
