9. (A) If a force of 25 Newton's is applied tangentially to the rim of a...
9. (A) If a force of 25 Newton's is applied tangentially to the rim of a uniform disk whose radius is .2 meters and mass is 30 kg, what angular velocity will the disk attain in .2 minutes? (B) What is the angular displacement (delta θ) during this acceration?
10. A disk-shaped wheel 1 meter in radius weighs 2000 Newton's. A force of 50 Newton's is applied tangentially to the rim. After how many seconds does it attain an angular velocity of 1200 rev/min?
Homework Answers
Add Answer to:
9. (A) If a force of 25 Newton's is applied tangentially to the
rim of a...
A constant force of 40N is applied tangentially to the rim of a wheel which is...
A constant force of 40N is applied tangentially to the rim of a wheel which is initially at rest as shown in fig below. The wheel has a moment of inertia of 30kg.m2, radius of circle is 0.2m Find: i. It’s Angular Acceleration ii. It’s angular velocity after 4 seconds iii. The no. of revolutions after 4 seconds iv. Show that the work done on the wheel after 4 seconds equals the Kinetic Energy possessed by the wheel after 4...
A force of 50 N is applied tangentially to the rim of a solid disk of...
A force of 50 N is applied tangentially to the rim of a solid disk of radius 0.18 m. The disk rotates about an axis through its center and perpendicular to its face with a constant angular acceleration of 115 rad/s2. Determine the mass of the disk.
In an experiment, a varying force is applied tangentially for a period of time to a...
In an experiment, a varying force is applied tangentially for a period of time to a solid disk mounted on a frictionless axle. Initially, the disk is at rest. Which type of graph should be created so that the final kinetic energy of the disk is represented by the area under the graph? Applied force as a function of angular speed Applied force as a function of angular acceleration Applied torque as a function of angular acceleration Applied force as...
Question 2 (8 marks) Applied force A vertical pulley, of radius 0.4 meter, can rotate about...
Question 2 (8 marks) Applied force A vertical pulley, of radius 0.4 meter, can rotate about a horizontal axle (axle has friction) that goes through its center. The rotational inertia of the pulley about this axle is 16 x 10 kg.m. The torque due to friction in the axle is constant, with magnitude 0.8 Nm. A vertical force, of constant magnitude 11.0 N, is continuously applied tangentially to the rim of the pulley as shown above. The pulley is initially...
5. A uniform circular wheel (I-M R) with radius, R=1.0 m and mass, M-50.0 kg is...
5. A uniform circular wheel (I-M R) with radius, R=1.0 m and mass, M-50.0 kg is spinning at 120 rev/min. At a particular moment of time (that we denote t-0) the wheel is subjected to a frictional force F=20.0 N applied tangentially at its rim. (a) The magnitude of the angular velocity of the wheel (in rad/s) after t=25 s is (b) The number of revolutions done by the wheel after 10 s
3) A uniform dis force F applied tangentially to the edge of the wheel acts to...
3) A uniform dis force F applied tangentially to the edge of the wheel acts to slow it down, through what angle does the wheel turn coming to a stop? k with mass M and radius R is turning at angular speed o. rolling without slipping. If a
A child exerts a tangential 61.9 N force on the rim of a disk-shaped merry-go-round with...
A child exerts a tangential 61.9 N force on the rim of a disk-shaped merry-go-round with a radius of 2.59 m. the merry-go-round starts at rest and acquires an angular speed of 0.8250 rev/s in 3.50 s, what is its mass
A child exerts a tangential 63.6 N force on the rim of a disk-shaped merry-go-round with...
A child exerts a tangential 63.6 N force on the rim of a disk-shaped merry-go-round with a radius of 2.59 m. If the merry-go-round starts at rest and acquires an angular speed of 0.8250 rev/s in 4.00 s, what is its mass?
A child exerts a tangential 51.7 N force on the rim of a disk-shaped merry-go-round with...
A child exerts a tangential 51.7 N force on the rim of a disk-shaped merry-go-round with a radius of 2.79 m. If the merry-go-round starts at rest and acquires an angular speed of 0.3250 rev/s in 3.00 s, what is its mass?
A child exerts a tangential 42.2 N force on the rim of a disk shaped merry go round with a radius of 2.40 m. If the me...
A child exerts a tangential 42.2 N force on the rim of a disk shaped merry go round with a radius of 2.40 m. If the merry-go-round starts at rest and acquires an angular speed of 0.0860 rev/s in 3.50s, what is its mass?
In an experiment, a varying force is applied tangentially for a period of time to a solid disk mounted on a frictionless axle. Initially, the disk is at rest. Which type of graph should be created so that the final kinetic energy of the disk is represented by the area under the graph? Applied force as a function of angular speed Applied force as a function of angular acceleration Applied torque as a function of angular acceleration Applied force as...
Question 2 (8 marks) Applied force A vertical pulley, of radius 0.4 meter, can rotate about a horizontal axle (axle has friction) that goes through its center. The rotational inertia of the pulley about this axle is 16 x 10 kg.m. The torque due to friction in the axle is constant, with magnitude 0.8 Nm. A vertical force, of constant magnitude 11.0 N, is continuously applied tangentially to the rim of the pulley as shown above. The pulley is initially...
5. A uniform circular wheel (I-M R) with radius, R=1.0 m and mass, M-50.0 kg is spinning at 120 rev/min. At a particular moment of time (that we denote t-0) the wheel is subjected to a frictional force F=20.0 N applied tangentially at its rim. (a) The magnitude of the angular velocity of the wheel (in rad/s) after t=25 s is (b) The number of revolutions done by the wheel after 10 s
3) A uniform dis force F applied tangentially to the edge of the wheel acts to slow it down, through what angle does the wheel turn coming to a stop? k with mass M and radius R is turning at angular speed o. rolling without slipping. If a
