The master cylinder of a hydraulic lift has a 0.01 m radius, while the slave has...

Question

Question

The master cylinder of a hydraulic lift has a 0.01 m radius, while the slave has a 0.20 m radius.

a. What force in N must be exerted on the master cylinder of a hydraulic lift to support the weight of a 2000 kg car resting on the slave cylinder?

b. What is the pressure in the fluid?

science physics

Answer 1

Answer #1

Answer 2
