What force must be exerted on the master cylinder of a hydraulic lift to support the...

What force must be exerted on the master cylinder of a hydraulic lift to support the weight of a 2500-kg car (a large car) resting on the slave cylinder? The master cylinder has a 3.00-cm diameter and the slave has a 24.0-cm diameter.

A) 136 N

B) 383 N

C) 245 N

D) 178 N

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
What force must be exerted on the master cylinder of a hydraulic lift to support the...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • What force (N) must be exerted on the master cylinder of a hydraulic lift to support...

    What force (N) must be exerted on the master cylinder of a hydraulic lift to support the weight of a 2300.0 kg car resting on the slave cylinder? The master cylinder has a 1,70 cm diameter, while the slave's is 24.0 cm.

  • Pascal’s principle: What force must be exerted on the master cylinder of a hydraulic lift to...

    Pascal’s principle: What force must be exerted on the master cylinder of a hydraulic lift to support the weight of a 1800 kg car resting on the slave cylinder? The master cylinder has a 2.00 cm diameter and the slave has a 25.0 cm diameter. Pascal’s principle: A barber’s chair rests on a hydraulic piston 10 cm in diameter. The input side has a piston with cross-sectional area of 10 cm2 which is pumped on using a foot pedal. If...

  • The master cylinder of a hydraulic lift has a 0.01 m radius, while the slave has...

    The master cylinder of a hydraulic lift has a 0.01 m radius, while the slave has a 0.20 m radius. a. What force in N must be exerted on the master cylinder of a hydraulic lift to support the weight of a 2000 kg car resting on the slave cylinder? b. What is the pressure in the fluid?

  • A hydraulic lift with a 25.0 cm diameter is supporting the weight of a 2930 kg...

    A hydraulic lift with a 25.0 cm diameter is supporting the weight of a 2930 kg vehicle (a large car or midsize SUV). (a) What force must be exerted on the 2.00 cm diameter master cylinder of this lift to support the vehicle resting on the other cylinder, the 25.0 cm diameter cylinder of the lift itself? 184 N (b) What gauge pressure must the hydraulic lines be capable of withstanding?

  • hydraulic lift with a 26.0 cm diameter is supporting the weight of a 2990 kg vehicle...

    hydraulic lift with a 26.0 cm diameter is supporting the weight of a 2990 kg vehicle (a large car or midsize SUV). (a) What force must be exerted on the 2.05 cm diameter master cylinder of this lift to support the vehicle resting on the other cylinder, the 26.0 cm diameter cylinder of the lift itself? Tries 0/15 (b) What gauge pressure must the hydraulic lines be capable of withstanding?

  • A hydraulic lift has pistons that are 1 cm and 15 cm in diameter. If a...

    A hydraulic lift has pistons that are 1 cm and 15 cm in diameter. If a force of 180 N is applied to the master cylinder, what is the largest mass that the lift can support?

  • QUESTION 5 Assuming bicycle tires are perfectly flexible and support the weight of bicycle and rider...

    QUESTION 5 Assuming bicycle tires are perfectly flexible and support the weight of bicycle and rider by pressure alone, calculate the total area of the tires in contact with the ground. The bicycle plus rider has a mass of 70 kg, and the gauge pressure in the tires is 5.4 105 Pa Express your answer in cm2 with 3 or more significant figures. QUESTION 6 How tall must a water-filed manometer be to measure blood pressures as high as 206...

  • QUESTION 6 How tall must a water-filled manometer be to measure blood pressures as high as...

    QUESTION 6 How tall must a water-filled manometer be to measure blood pressures as high as 206 mm Hg? (Express your answer in Sl units with 3 or more significant figures) ( Phpg) Density of water = 1 g/cm? Density of mercury 136 g/cm? QUESTION 7 What force must be exerted on the master cylinder of a hydraulic in to support the weight of a 1.231 kg car resting on the slave cylinder? The master cylinder has a 27 cm...

  • What force must be applied to a 2.5 cm diameter piston in a hydraulic lift system...

    What force must be applied to a 2.5 cm diameter piston in a hydraulic lift system i order to lift a truck of mass 1210 kg upon a platform supported by a 15 cm diameter piston?

  • Need ASAP To inspect a 20, 500 N car, it is raised with a hydraulic lift,...

    Need ASAP To inspect a 20, 500 N car, it is raised with a hydraulic lift, if the radius of the small piston is 5.0 cm, and the radius of the large it is position is 10 cm, find the force that must be exerted on the small piston to lift the car.
