A battery is used to charge a parallel-plate capacitor so that the magnitude of the potential...
A battery is used to charge a parallel-plate capacitor so that the magnitude of the potential difference between its plates is 16.0 V. The capacitor is disconnected from the battery (so the amount of charge on each plate cannot change), and a material with a dielectric constant of 3.49 is inserted between the plates. Find the new potential difference between the plates.
Homework Answers
Add Answer to:
A battery is used to charge a parallel-plate capacitor so that
the magnitude of the potential...
The plates of an air-filled parallel-plate capacitor with a plate area of 16.5 cm2 and a...
The plates of an air-filled parallel-plate capacitor with a plate area of 16.5 cm2 and a separation of 8.80 mm are charged to a 130-V potential difference. After the plates are disconnected from the source, a porcelain dielectric with κ = 6.5 is inserted between the plates of the capacitor. (a) What is the charge on the capacitor before and after the dielectric is inserted? Qi = ___C Qf = ____C (b) What is the capacitance of the capacitor after...
A parallel-plate capacitor has plates of area 0.13 m2 and a separation of 1.9 cm. A battery...
A parallel-plate capacitor has plates of area 0.13 m2 and a separation of 1.9 cm. A battery charges the plates to a potential difference of 150 V and is then disconnected. A dielectric slab of thickness 9.3 mm and dielectric constant 4.0 is then placed symmetrically between the plates. (a) What is the capacitance before the slab is inserted? (b) What is the capacitance with the slab in place? What is the free charge q (c) before and (d) after the slab is inserted? What is the magnitude of the...
A parallel-plate capacitor filled with air carries a charge Q. The battery is disconnected, and a...
A parallel-plate capacitor filled with air carries a charge Q. The battery is disconnected, and a slab of material with dielectric constant k = 2 is inserted between the plates. Which of the following statements is correct? The voltage across the capacitor decreases by a factor of 2. The voltage across the capacitor is doubled. The electric field is doubled. The charge on the plates decreases by a factor of 2. The charge on the plates is doubled.
A parallel-plate capacitor has plate area of 0.12 m2and plate separation 1.2 cm. It is charged...
A parallel-plate capacitor has plate area of 0.12 m2and plate separation 1.2 cm. It is charged by a battery to potential difference of 120 V, then disconnected. A dielectric slab, thickness 4.0 mm and dielectric constant 4.8, is placed symmetrically between the plates.(a) Calculate the capacitance before and after the slab is inserted.(b) Calculate the free charge q before and after the slab is inserted.(c) Calculate the magnitude of the electric field in the space between the plates and the...
A 193 volt battery is connected to a 0.3 microfarad parallel-plate capacitor with air between the...
A 193 volt battery is connected to a 0.3 microfarad parallel-plate capacitor with air between the plates. Now the battery is disconnected, with care taken not to discharge the capacitor. Some paper is then inserted between the plates completely filling up the space. What is the final potential difference between the plates ? (the dielectric constant for air is = 1 and for the paper inserted is = 3)
An empty parallel plate capacitor is connected to a battery that maintains a constant potential difference...
An empty parallel plate capacitor is connected to a battery that maintains a constant potential difference between the plates. With the battery connected, a dielectric is then inserted between the plates. Does the energy stored by the capacitor increase, decrease or remain the same when the dielectric is inserted? remain the same decrease increase
A parallel-plate capacitor with only air between the plates is charged by connecting it to a...
A parallel-plate capacitor with only air between the plates is charged by connecting it to a battery. The capacitor is then disconnected from the battery, without any of the charge leaving the plates. A. A voltmeter reads 44.0 V when placed across the capacitor. When a dielectric is inserted between the plates, completely filling the space, the voltmeter reads 11.0 V . What is the dielectric constant of this material? B. What will the voltmeter read if the dielectric is...
A parallel plate capacitor of capacitance Co has plates of area A with separation d between...
A parallel plate capacitor of capacitance Co has plates of area A with separation d between them. When it is connected to a battery of voltage Vo, it has a charge of magnitude Qo on its plates. It is then disconnected from the battery and the space between the plates is filled with a material of dielectric constant 3. After the dielectric is added, the magnitudes of the charge on the plates and the potential difference between them are 15.
A parallel-plate capacitor has charge of magnitude 8.40 µC on each plate and capacitance 3.60 µF when there is air between the plates.
A parallel-plate capacitor has charge of magnitude 8.40 µC on each plate and capacitance 3.60 µF when there is air between the plates. The plates are separated by 2.10 mm. With the charge on the plates kept constant, a dielectric withκ = 6is inserted between the plates, completely filling the volume between the plates. (Enter the magnitudes.)(a)What is the potential difference between the plates of the capacitor (in V) before and after the dielectric has been inserted?before Vafter V(b)What is...
Constants Part A A parallel-plate capacitor with only air between the plates is charged by connecting...
Constants Part A A parallel-plate capacitor with only air between the plates is charged by connecting it to a battery The capacitor is then disconnected from the battery without any of the charge leaving the plates A voltmeter reads 49 0 V when placed across the capacitor When a dielectric is inserted between the plates, completely filling the space, the voltmeter reads 14.5 V What is the dielectric constant of this material? Part B What will the voltmeter read il...
A parallel plate capacitor of capacitance Co has plates of area A with separation d between them. When it is connected to a battery of voltage Vo, it has a charge of magnitude Qo on its plates. It is then disconnected from the battery and the space between the plates is filled with a material of dielectric constant 3. After the dielectric is added, the magnitudes of the charge on the plates and the potential difference between them are 15.
Constants Part A A parallel-plate capacitor with only air between the plates is charged by connecting it to a battery The capacitor is then disconnected from the battery without any of the charge leaving the plates A voltmeter reads 49 0 V when placed across the capacitor When a dielectric is inserted between the plates, completely filling the space, the voltmeter reads 14.5 V What is the dielectric constant of this material? Part B What will the voltmeter read il...
