Determine Ecell (in V) at 298.15 K for a cell composed of a platinum electrode in...

Determine Ecell (in V) at 298.15 K for a cell composed of a platinum electrode in a mixture of 0.629 M Fe2+and 0.163 M Fe3+ coupled to a platinum electrode in a solution where the [H+] is 1.546 M and the partial pressure of H2 is 0.709 atm.

science   chemistry
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

to solve this problem we need the standats reduction potential of Fe+3/Fe+2 which is .77 volt while standard reduction potential of hydrogen is 0.0 volt and then applying nerst equation.

0 0
