A proton with charge 1.602 x 10^-19 C moves at a speed of 300 m/s in...

A proton with charge 1.602 x 10^-19 C moves at a speed of 300 m/s in a magnetic field at an angle of 65 degrees. If the strength of the magnetic field is 19 T, what would be the magnitude of the force the charge experiences?

8.28 x 10^-16 N
13.78 x 10^-15 N
5.09 x 10^-14 N
7.75 x 10^-17 N

An alpha particle travelling at 2155 m/s enters a magnetic field of strength 12.2 T. The particle is moving horizontally and the magnetic field is vertical. If an alpha particle contains two protons, each with a charge of 1.602 x 10^-19 C and the particle has a mass of 6.64 x 10^-22 kg, what is the radius of the circular path the particle will travel in?

0.366 m
0.918 m
0.106 m
0.672 m

What is the cyclotron frequency of an electron entering a magnetic field of strength 0.0045 T? The charge of an electron is -1.602 x 10^-19 C and the mass of an electron is 9.31 x 10^-31 kg (1 point)

2.87 x 10^8 Hz
5.19 x 10^7 Hz
1.23 x 10^8 Hz
3.44 x 10^9 Hz
science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A proton with charge 1.602 x 10^-19 C moves at a speed of 300 m/s in...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • An electron (charge≈ 1.602 × 10−19 C; mass≈ 9.109 × 10−31 kg) moving at speed 200...

    An electron (charge≈ 1.602 × 10−19 C; mass≈ 9.109 × 10−31 kg) moving at speed 200 m/s finds itself in a region of constant magnetic field. The magnetic field points perpendicular to the electron velocity and has strength 10−3 Tesla. (a) Find the magnitude of the magnetic force experienced by the electron. (b) The magnetic force causes cyclotron motion, so that the electron moves around a circular trajectory. Find the radius of the circular trajectory. (c) How long does it...

  • Alpha particles (charge = +2e, mass = 6.68 x 10^-27 kg) are accelerated in a cyclotron...

    Alpha particles (charge = +2e, mass = 6.68 x 10^-27 kg) are accelerated in a cyclotron to a final orbit radius of 0.50 m. The magnetic field in the cyclotron is 0.50 T. The kinetic energy of an alpha particle in the final orbit is closest to: 22)_______

  • An electron (charge= -1.6 x 10^-19 C) is moving at 3 x 10^5 m/s in the...

    An electron (charge= -1.6 x 10^-19 C) is moving at 3 x 10^5 m/s in the positive x direction. A magnetic field of 0.8 T is in the positive z direction. What are the magnitude and direction on the magnetic force on the electron?

  • A particle with charge q and mass m moves in a horizontal plane at right angles...

    A particle with charge q and mass m moves in a horizontal plane at right angles to a uniform vertical magnetic field B. a) Compute the path radius if the particle is an electron with a speed of 1.0×105 m/s traveling in a region where the field strength is 0.10 mT . answer in mm b) What is the cyclotron frequency? answer in MHz

  • Calculate the period of a proton moving at 2.5 x 107 m/s perpendicularly to a 1.2T...

    Calculate the period of a proton moving at 2.5 x 107 m/s perpendicularly to a 1.2T field of a cyclotron. mass of a proton = 1.67 x 10-27 kg charge on a proton = 1.602 x 10-19 C

  • s. A proton, m 1.6726 x 1027 kg, q = 1.602 x 1019 [CI, moves in...

    s. A proton, m 1.6726 x 1027 kg, q = 1.602 x 1019 [CI, moves in a circular path of radius r 0.03 [mi, perpendicular to the magnetic field B-5 [μη into the page. Find a. v, velocity b. Fa, magnetic force c. T, the period (the time for one complete circle) Bin

  • Consider the path of the proton (q = 1.602 × 10−19 C, m = 1.673 ×...

    Consider the path of the proton (q = 1.602 × 10−19 C, m = 1.673 × 10−27 kg) in a uniform electric and magnetic field. Both fields are in the z direction, B⃗ = B0k? and E⃗ = E0k?, where B0 = 55 mT and E0 = 180 V / m. At time t = 0, the proton moves at v⃗ = v0?ı, v0 = 150 km / s. Based on this information, what kind of orbit does the proton...

  • As shown in the figure, an electron is fired with a speed of 3.73 x 10...

    As shown in the figure, an electron is fired with a speed of 3.73 x 10 m/s through a hole in one of the two parallel plates and into the region between the plates separated by a distance of 0.24 m. There is a magnetic field in the region between the plates and, as shown, it is directed into the plane of the page (perpendicular to the velocity of the electron). Determine the magnitude of the magnetic field so that...

  • An electron (charge -1.6 x 10^-19 C) moves on a path perpendicular to the direction of...

    An electron (charge -1.6 x 10^-19 C) moves on a path perpendicular to the direction of a uniform electric field of strength 3.0 N/C. How much work is done on the electron as it moves 15 cm? 4.8 x 10^20 J 0.55 x 10^20 J 0.72 x 10^-20 J

  • A beam of particles, each with a charge of 11.2 x 10-19 C, moves at [...

    A beam of particles, each with a charge of 11.2 x 10-19 C, moves at [ (-8.13)i + (-7.69)j + (-1.24)k ] x 105 m/s through a uniform magnetic field of [ (4.97)i + (1.01)j + (-1.61)k ] T. Let F represent the force vector on each particle. Small number entry: use 1.24e-14 N to enter 1.24x10-14 N What is the i component of F? What is the j component of F? What is the k component of F? What...
