a force of 25N is applied at f. if the diameter of the piston at f...

Question

Question

a force of 25N is applied at f. if the diameter of the piston at f is 16mm and the diameter of the piston at F is 310mm, what is the value of F?

v

science physics

Answer 1

Answer #1

Answer 2
