Question

1.) A cmos inverter can be constructed by using one enhancement type nmos and one enhancement...

1.) A cmos inverter can be constructed by using one enhancement type nmos and one enhancement type pmos is connected by____
placing them in series with the pmos above

placing them in series with the nmos above

placing then in parallel with the pmos on the left

placing then in parallel with the nmos on the left

2) A PMOS with the source connected to a 10V and drain connected to ground, can be turned on by applying a gate-to-drain voltage of ___.

VDS=0V

VDS=10V

VDS=20V

None of the choices

3) An NMOS with the source connected to a 10V and drain connected to ground, can be turned on by applying a gate-to-drain voltage of ___.

VGS=0V

VGS=10V

VGS=-10V

None of the choices

4.) After VDS reaches pinch off voltage VP in a JFET, the drain current becomes____

zero

low

saturated

reversed

5.) The Id vs VGS curve of an n-channel and p channel JFET lies on the ___ and ___ quadrant respectively.

first quadrant

second

third

fourth

6.) A CMOS NAND gate can be constructed by connecting PMOS in ____ and NMOS in ____.

series,series

series, parallel

parallel, series

parallel, parallel

no solutions needed. thank you
