Question 5 4 pts Consider the portion of a project depicted by this graph: 5 What is the latest start time of activity 6-7 if
business   Operations-Management
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

The correct answer is option 4

-----------------------------------------------------------------------------------------

Latest start time of activity 6 - 7 = Latest finish of activity (6-7) - activity time of ( 6 - 7)

Latest finish of activity 6- 7 = Minimum of latest start of activity (7-8) , ( 7 - 9)

Latest start of activity (7-8) = 26 - 8 = 18

Latest start of activity ( 7 - 9) = 23 - 6 = 17

Latest finish of activity 6- 7 = Minimum of latest start of activity (7-8) , ( 7 - 9) = 17

Latest start of activity (6 - 7) = 17 - 5 = 12
